The Battery Storage Systems by Mediant Systems Pvt. Ltd. is an advanced 1-phase, 2-wire, 240V AC, 50Hz meter designed for efficient energy measurement and management. It provides accurate energy consumption data with Class 1 accuracy as per IS 13779/IS 16444 standards. Equipped with RF, GPRS 4G, Bluetooth, Wi-Fi, and Optical Port communication capabilities, it ensures seamless remote monitoring and data transmission. The meter is built with anti-tamper features, power outage detection, and self-diagnostic functions, making it ideal for modern electricity distribution networks. It supports net metering, real-time energy monitoring, and secure polycarbonate sealing, ensuring durability and security.
Specifications of Single-Phase Smart Meter
- Type: 1 Phase, 2 Wire, 240VAC, 50Hz
- Accuracy Class: Class 1 as per IS 13779/IS 16444
- Current Range: Ib 5A, Imax 80A
- Operating Voltage: 240V (+20%, -40%)
- Operating Frequency: 50Hz ± 5%
- Starting Current: 0.2% Ib at 240V, Unity Power Factor
- Power Consumption:
- Voltage Circuit: 7W (under communication), 5W, 15VA
- Current Circuit: 4VA
- Short Time Overcurrent: 30Imax for half cycle
- Power Factor Range: Zero Lag to Unity
- Degree of Protection: IP51
- Resistance to Heat & Fire: As per IS 13779:99
- Electromagnetic Compatibility (EMC): Yes
- Tamper Detection:
- Immune to DC tampering (Phase & Neutral)
- Detects magnetic tampering & abnormal energy usage events
- Logs tamper events with date & time stamps
- Under tamper conditions, the meter disconnects after a warning
- Communication Protocols: RF 865 – 867 MHz, GPRS 4G (fallback to 2G), Bluetooth, Wi-Fi, RS-485, Optical Port
- Remote Firmware Updates (FOTA): DLMS compliant
- Power Failure Alerts: Sends notifications during power failures
- Self-Diagnostic Feature: Displays all segments on LCD at startup
- Net Metering Support: Yes
- Display Type: Backlit LCD (Green, Pin Type, STN, 120° Viewing Angle)
- Pulse Rate: 3200 imp/kWh
- Memory Retention: EEPROM, more than 20 years
- Measuring Elements: Shunt in Phase, CT in Neutral
- Withstand Voltage:
- Impulse Voltage: 6kV, 100E impedance
- AC Withstand Voltage: 4kV (Body to Terminals)
- Insulation Resistance:
- Frame to Current/Voltage Circuits: > 5MΩ
- Between Circuits: > 50MΩ
- Sealing: Polycarbonate seals with serial number & logo
- Fire Retardant Material:
- Meter Body: PC (Polycarbonate), 2mm Thickness
- Terminal Block: Integral part of the base body
- Terminal Screws: M6, Nickel Plated Brass
- Ultrasonic Welding for Base & Cover: Glued & Locked
- Startup Time: Fully functional within 5 seconds of power application
- Optical Port: RS232 (D9) Connector for termination in the meter box
- Disconnector Switch:
- Make: HONGFA/KG/EVE
- Two single-pole relays (90A) used in Phase & Neutral Circuit
- Tamper Counters: Yes
- Routine & Acceptance Test Certificates: Applied for
This Single-Phase Smart Meter is designed for electricity boards, AMR/AMI applications, and smart energy management systems, ensuring high efficiency, security, and reliable remote communication.
Brief Description of PCP Smart Meter
The PCP Single-Phase Smart Meter is a state-of-the-art electricity metering device designed for accurate energy measurement, real-time monitoring, and remote communication. It operates on a 1-phase, 2-wire, 240V AC, 50Hz system, ensuring high precision and reliability as per IS 13779/IS 16444 standards. The smart meter is equipped with tamper detection, net metering support, and multiple communication options (RF, GPRS 4G, Bluetooth, Wi-Fi, Optical Port), making it ideal for residential, commercial, and industrial applications. With its robust security features and energy-efficient design, the PCP Smart Meter enhances electricity management, reduces losses, and improves billing accuracy.
Specifications of PCP Single-Phase Smart Meter
- Type: 1 Phase, 2 Wire, 240V AC, 50Hz
- Accuracy Class: Class 1 as per IS 13779/IS 16444
- Current Range: Ib 5A, Imax 80A
- Operating Voltage: 240V (+20%, -40%)
- Starting Current: 0.2% Ib at 240V, Unity Power Factor
- Power Consumption:
- Voltage Circuit: 7W (under communication), 5W, 15VA
- Current Circuit: 4VA
- Short Time Overcurrent: 30Imax for half cycle
- Power Factor Range: Zero Lag to Unity
- Degree of Protection: IP51
- Resistance to Heat & Fire: As per IS 13779:99
- Electromagnetic Compatibility (EMC): Yes
- Tamper Detection:
- Immune to DC tampering (Phase & Neutral)
- Detects magnetic tampering & abnormal energy usage events
- Logs tamper events with date & time stamps
- Under tamper conditions, the meter disconnects after a warning
- Communication Protocols: RF 865 – 867 MHz, GPRS 4G (fallback to 2G), Bluetooth, Wi-Fi, RS-485, Optical Port
- Remote Firmware Updates (FOTA): DLMS compliant
- Power Failure Alerts: Sends notifications during power failures
- Self-Diagnostic Feature: Displays all segments on LCD at startup
- Net Metering Support: Yes
- Display Type: Backlit LCD (Green, Pin Type, STN, 120° Viewing Angle)
- Pulse Rate: 3200 imp/kWh
- Memory Retention: EEPROM, more than 20 years
- Measuring Elements: Shunt in Phase, CT in Neutral
- Withstand Voltage:
- Impulse Voltage: 6kV, 100E impedance
- AC Withstand Voltage: 4kV (Body to Terminals)
- Insulation Resistance:
- Frame to Current/Voltage Circuits: > 5MΩ
- Between Circuits: > 50MΩ
- Sealing: Polycarbonate seals with serial number & logo
- Fire Retardant Material:
- Meter Body: PC (Polycarbonate), 2mm Thickness
- Terminal Block: Integral part of the base body
- Terminal Screws: M6, Nickel Plated Brass
- Ultrasonic Welding for Base & Cover: Glued & Locked
- Startup Time: Fully functional within 5 seconds of power application
- Optical Port: RS232 (D9) Connector for termination in the meter box
- Disconnector Switch:
- Make: HONGFA/KG/EVE
- Two single-pole relays (90A) used in Phase & Neutral Circuit
- Tamper Counters: Yes
- Routine & Acceptance Test Certificates: Applied for
The PCP Single-Phase Smart Meter is a modern and intelligent metering solution designed to enhance energy efficiency, security, and accurate billing. With real-time tracking, remote communication, and tamper-proof features, it is an essential component for smart grids, AMI applications, and efficient electricity management.
Brief Description of Mediant Three-Phase Smart Meter
The Mediant Three-Phase Smart Meter is an advanced energy metering solution designed for accurate, real-time electricity monitoring and management. It is a 3-phase, 4-wire, direct-reading meter that ensures high precision with Class 1 accuracy as per IS 13779/IS 16444 standards. The meter is equipped with tamper detection, net metering capabilities, and remote communication features such as RF, GPRS 4G, Bluetooth, Wi-Fi, RS-485, and Optical Port, making it suitable for electricity boards, AMR/AMI applications, and industrial energy monitoring. With its robust security features, energy efficiency, and remote firmware update capabilities (FOTA), it enhances power distribution management while reducing energy losses.
Specifications of Mediant Three-Phase Smart Meter
- Type: 3 Phase, 4 Wire, Whole Current Meter, Direct Reading Type
- Accuracy Class: Class 1 as per IS 13779/IS 16444
- Current Range: Ib 5A, Imax 100A
- Operating Voltage:240V (+20%, -40%)
- Operating Frequency:50Hz ± 5%
- Power Consumption:
- Voltage Circuit: 7W (under communication), 5W, 15VA
- Current Circuit: 4VA
- Short Time Overcurrent: 50 Imax for half cycle
- Power Factor Range: Zero Lag to Unity
- Degree of Protection: IP51 as per IS 12063
- Resistance to Heat & Fire: As per IS 13779:99
- Electromagnetic Compatibility (EMC): Yes, as per IS 13779:99
- Tamper Detection:
- Immune to stray magnetic fields, abnormal magnetic interference, and DC tampering
- Logs tamper events with date & time stamps
- Disconnects power supply under tamper conditions after a warning
- Communication Protocols: RF 865 – 867 MHz, GPRS 4G (fallback to 2G), Bluetooth, Wi-Fi, RS-485, Optical Port
- Remote Firmware Updates (FOTA): DLMS compliant
- Power Failure Alerts: Sends notifications during power failures
- Self-Diagnostic Feature: Displays all segments on LCD at startup
- Net Metering Support: Yes
- Display Type:Backlit LCD (Green, Pin Type, STN, 120° Viewing Angle)
- Pulse Rate: 1600 imp/kWh
- Memory Retention:EEPROM, more than 20 years
- Measuring Elements: Shunt in Phase, CT in Neutral
- Startup Time:Fully functional within 5 seconds of power application
- Withstand Voltage:
- Impulse Voltage: 8kV, 100E impedancee
- AC Withstand Voltage: 4kV (Body to Terminals)
- Insulation Resistance:
- Frame to Current/Voltage Circuits: > >5MΩ
- Between Circuits: > >50MΩ
- Sealing: Polycarbonate seals with serial number & logo
- Fire Retardant Material:
- Meter Body: PC (Polycarbonate), 2mm Thickness
- Terminal Block: Integral part of the base body
- Terminal Screws: M6, Nickel Plated Brass
- Ultrasonic Welding for Base & Cover: Glued & Locked
- Optical Port:Additional RS232 (D9) Connector for termination in the meter box
- Disconnector Switch:
- Make: HONGFA/KG/EVE
- Two single-pole relays (90A) used in Phase & Neutral Circuit
- Tamper Counters: Yes
- Type Test Certified:IS 16444 Certified
- Power Supply Backup:Super Cap, then Battery
The Mediant Three-Phase Smart Meter is a highly advanced metering solution designed to optimize energy efficiency, ensure accurate billing, and enhance security. Its real-time tracking, remote communication, and tamper-proof features make it a key component for smart grids, industrial applications, and AMI-based energy management systems.
Brief Description of PCP Three-Phase Smart Meter
The PCP Three-Phase Smart Meter is a high-precision energy metering device designed for accurate monitoring, real-time data collection, and secure energy management. It is a 3-phase, 4-wire, direct-reading meter that ensures reliable performance with Class 1 accuracy as per IS 13779/IS 16444 standards. Equipped with tamper detection, net metering capabilities, and multiple communication protocols (RF, GPRS 4G, Bluetooth, Wi-Fi, RS-485, Optical Port), this smart meter is ideal for industrial, commercial, and smart grid applications.With its remote firmware update (FOTA) capabilities, advanced security features, and energy efficiency, the PCP Three-Phase Smart Meter enhances power distribution management while minimizing energy losses. It supports real-time monitoring, automated billing, and seamless integration with Advanced Metering Infrastructure (AMI), making it a smart solution for modern energy systems.
Specifications of PCP Three-Phase Smart Meter
- Type: 3 Phase, 4 Wire, Whole Current Meter, Direct Reading Type
- Accuracy Class: Class 1 as per IS 13779/IS 16444
- Current Range: Ib 5A, Imax 100A
- Operating Voltage:240V (+20%, -40%)
- Operating Frequency:50Hz ± 5%
- Power Consumption:
- Voltage Circuit: 7W (under communication), 5W, 15VA
- Current Circuit: 4VA
- Short Time Overcurrent: 50 Imax for half cycle
- Power Factor Range: Zero Lag to Unity
- Degree of Protection: IP51 as per IS 12063
- Resistance to Heat & Fire: As per IS 13779:99
- Electromagnetic Compatibility (EMC): Yes, as per IS 13779:99
- Tamper Detection:
- Immune to stray magnetic fields, abnormal magnetic interference, and DC tampering
- Logs tamper events with date & time stamps
- Disconnects power supply under tamper conditions after a warning
- Communication Protocols: RF 865 – 867 MHz, GPRS 4G (fallback to 2G), Bluetooth, Wi-Fi, RS-485, Optical Port
- Remote Firmware Updates (FOTA): DLMS compliant
- Power Failure Alerts: Sends notifications during power failures
- Self-Diagnostic Feature: Displays all segments on LCD at startup
- Net Metering Support: Yes
- Display Type:Backlit LCD (Green, Pin Type, STN, 120° Viewing Angle)
- Pulse Rate: 1600 imp/kWh
- Memory Retention:EEPROM, more than 20 years
- Measuring Elements: Shunt in Phase, CT in Neutral
- Startup Time:Fully functional within 5 seconds of power application
- Withstand Voltage:
- Impulse Voltage: 8kV, 100E impedancee
- AC Withstand Voltage: 4kV (Body to Terminals)
- Insulation Resistance:
- Frame to Current/Voltage Circuits: > >5MΩ
- Between Circuits: > >50MΩ
- Sealing: Polycarbonate seals with serial number & logo
- Fire Retardant Material:
- Meter Body: PC (Polycarbonate), 2mm Thickness
- Terminal Block: Integral part of the base body
- Terminal Screws: M6, Nickel Plated Brass
- Ultrasonic Welding for Base & Cover: Glued & Locked
- Optical Port:Additional RS232 (D9) Connector for termination in the meter box
- Disconnector Switch:
- Make: HONGFA/KG/EVE
- Two single-pole relays (90A) used in Phase & Neutral Circuit
- Tamper Counters: Yes
- Type Test Certified:IS 16444 Certified
- Power Supply Backup:Super Cap, then Battery
The Mediant Three-Phase Smart Meter is a highly advanced metering solution designed to optimize energy efficiency, ensure accurate billing, and enhance security. Its real-time tracking, remote communication, and tamper-proof features make it a key component for smart grids, industrial applications, and AMI-based energy management systems.
Brief Description of PCP Three-Phase Smart Meter
The PCP Three-Phase Smart Meter is a high-precision energy metering device designed for accurate monitoring, real-time data collection, and secure energy management. It is a 3-phase, 4-wire, direct-reading meter that ensures reliable performance with Class 1 accuracy as per IS 13779/IS 16444 standards. Equipped with tamper detection, net metering capabilities, and multiple communication protocols (RF, GPRS 4G, Bluetooth, Wi-Fi, RS-485, Optical Port), this smart meter is ideal for industrial, commercial, and smart grid applications.With its remote firmware update (FOTA) capabilities, advanced security features, and energy efficiency, the PCP Three-Phase Smart Meter enhances power distribution management while minimizing energy losses. It supports real-time monitoring, automated billing, and seamless integration with Advanced Metering Infrastructure (AMI), making it a smart solution for modern energy systems.
Specifications of PCP Three-Phase Smart Meter
- Type: 3 Phase, 4 Wire, Whole Current Meter, Direct Reading Type
- Accuracy Class: Class 1 as per IS 13779/IS 16444
- Current Range: Ib 5A, Imax 100A
- Operating Voltage:240V (+20%, -40%)
- Operating Frequency:50Hz ± 5%
- Power Consumption:
- Voltage Circuit: 7W (under communication), 5W, 15VA
- Current Circuit: 4VA
- Short Time Overcurrent: 50 Imax for half cycle
- Power Factor Range: Zero Lag to Unity
- Degree of Protection: IP51 as per IS 12063
- Resistance to Heat & Fire: As per IS 13779:99
- Electromagnetic Compatibility (EMC): Yes, as per IS 13779:99
- Tamper Detection:
- Immune to stray magnetic fields, abnormal magnetic interference, and DC tampering
- Logs tamper events with date & time stamps
- Disconnects power supply under tamper conditions after a warning
- Communication Protocols: RF 865 – 867 MHz, GPRS 4G (fallback to 2G), Bluetooth, Wi-Fi, RS-485, Optical Port
- Remote Firmware Updates (FOTA): DLMS compliant
- Power Failure Alerts: Sends notifications during power failures
- Self-Diagnostic Feature: Displays all segments on LCD at startup
- Net Metering Support: Yes
- Display Type:Backlit LCD (Green, Pin Type, STN, 120° Viewing Angle)
- Pulse Rate: 1600 imp/kWh
- Memory Retention:EEPROM, more than 20 years
- Measuring Elements: Shunt in Phase, CT in Neutral
- Startup Time:Fully functional within 5 seconds of power application
- Withstand Voltage:
- Impulse Voltage: 8kV, 100E impedancee
- AC Withstand Voltage: 4kV (Body to Terminals)
- Insulation Resistance:
- Frame to Current/Voltage Circuits: > >5MΩ
- Between Circuits: > >50MΩ
- Sealing: Polycarbonate seals with serial number & logo
- Fire Retardant Material:
- Meter Body: PC (Polycarbonate), 2mm Thickness
- Terminal Block: Integral part of the base body
- Terminal Screws: M6, Nickel Plated Brass
- Ultrasonic Welding for Base & Cover: Glued & Locked
- Optical Port:Additional RS232 (D9) Connector for termination in the meter box
- Disconnector Switch:
- Make: HONGFA/KG/EVE
- Two single-pole relays (90A) used in Phase & Neutral Circuit
- Tamper Counters: Yes
- Type Test Certified:IS 16444 Certified
- Power Supply Backup:Super Cap, then Battery
The Mediant Three-Phase Smart Meter is a highly advanced metering solution designed to optimize energy efficiency, ensure accurate billing, and enhance security. Its real-time tracking, remote communication, and tamper-proof features make it a key component for smart grids, industrial applications, and AMI-based energy management systems.
Brief Description of PCP Three-Phase Smart Meter
The PCP Three-Phase Smart Meter is a high-precision energy metering device designed for accurate monitoring, real-time data collection, and secure energy management. It is a 3-phase, 4-wire, direct-reading meter that ensures reliable performance with Class 1 accuracy as per IS 13779/IS 16444 standards. Equipped with tamper detection, net metering capabilities, and multiple communication protocols (RF, GPRS 4G, Bluetooth, Wi-Fi, RS-485, Optical Port), this smart meter is ideal for industrial, commercial, and smart grid applications.With its remote firmware update (FOTA) capabilities, advanced security features, and energy efficiency, the PCP Three-Phase Smart Meter enhances power distribution management while minimizing energy losses. It supports real-time monitoring, automated billing, and seamless integration with Advanced Metering Infrastructure (AMI), making it a smart solution for modern energy systems.
Specifications of PCP Three-Phase Smart Meter
- Type: 3 Phase, 4 Wire, Whole Current Meter, Direct Reading Type
- Accuracy Class: Class 1 as per IS 13779/IS 16444
- Current Range: Ib 5A, Imax 100A
- Operating Voltage:240V (+20%, -40%)
- Operating Frequency:50Hz ± 5%
- Power Consumption:
- Voltage Circuit: 7W (under communication), 5W, 15VA
- Current Circuit: 4VA
- Short Time Overcurrent: 50 Imax for half cycle
- Power Factor Range: Zero Lag to Unity
- Degree of Protection: IP51 as per IS 12063
- Resistance to Heat & Fire: As per IS 13779:99
- Electromagnetic Compatibility (EMC): Yes, as per IS 13779:99
- Tamper Detection:
- Immune to stray magnetic fields, abnormal magnetic interference, and DC tampering
- Logs tamper events with date & time stamps
- Disconnects power supply under tamper conditions after a warning
- Communication Protocols: RF 865 – 867 MHz, GPRS 4G (fallback to 2G), Bluetooth, Wi-Fi, RS-485, Optical Port
- Remote Firmware Updates (FOTA): DLMS compliant
- Power Failure Alerts: Sends notifications during power failures
- Self-Diagnostic Feature: Displays all segments on LCD at startup
- Net Metering Support: Yes
- Display Type:Backlit LCD (Green, Pin Type, STN, 120° Viewing Angle)
- Pulse Rate: 1600 imp/kWh
- Memory Retention:EEPROM, more than 20 years
- Measuring Elements: Shunt in Phase, CT in Neutral
- Startup Time:Fully functional within 5 seconds of power application
- Withstand Voltage:
- Impulse Voltage: 8kV, 100E impedancee
- AC Withstand Voltage: 4kV (Body to Terminals)
- Insulation Resistance:
- Frame to Current/Voltage Circuits: > >5MΩ
- Between Circuits: > >50MΩ
- Sealing: Polycarbonate seals with serial number & logo
- Fire Retardant Material:
- Meter Body: PC (Polycarbonate), 2mm Thickness
- Terminal Block: Integral part of the base body
- Terminal Screws: M6, Nickel Plated Brass
- Ultrasonic Welding for Base & Cover: Glued & Locked
- Optical Port:Additional RS232 (D9) Connector for termination in the meter box
- Disconnector Switch:
- Make: HONGFA/KG/EVE
- Two single-pole relays (90A) used in Phase & Neutral Circuit
- Tamper Counters: Yes
- Type Test Certified:IS 16444 Certified
- Power Supply Backup:Super Cap, then Battery
The Mediant Three-Phase Smart Meter is a highly advanced metering solution designed to optimize energy efficiency, ensure accurate billing, and enhance security. Its real-time tracking, remote communication, and tamper-proof features make it a key component for smart grids, industrial applications, and AMI-based energy management systems.
Brief Description of PCP Three-Phase Smart Meter
The PCP Three-Phase Smart Meter is a high-precision energy metering device designed for accurate monitoring, real-time data collection, and secure energy management. It is a 3-phase, 4-wire, direct-reading meter that ensures reliable performance with Class 1 accuracy as per IS 13779/IS 16444 standards. Equipped with tamper detection, net metering capabilities, and multiple communication protocols (RF, GPRS 4G, Bluetooth, Wi-Fi, RS-485, Optical Port), this smart meter is ideal for industrial, commercial, and smart grid applications.With its remote firmware update (FOTA) capabilities, advanced security features, and energy efficiency, the PCP Three-Phase Smart Meter enhances power distribution management while minimizing energy losses. It supports real-time monitoring, automated billing, and seamless integration with Advanced Metering Infrastructure (AMI), making it a smart solution for modern energy systems.
Specifications of PCP Three-Phase Smart Meter
- Type: 3 Phase, 4 Wire, Whole Current Meter, Direct Reading Type
- Accuracy Class: Class 1 as per IS 13779/IS 16444
- Current Range: Ib 5A, Imax 100A
- Operating Voltage:240V (+20%, -40%)
- Operating Frequency:50Hz ± 5%
- Power Consumption:
- Voltage Circuit: 7W (under communication), 5W, 15VA
- Current Circuit: 4VA
- Short Time Overcurrent: 50 Imax for half cycle
- Power Factor Range: Zero Lag to Unity
- Degree of Protection: IP51 as per IS 12063
- Resistance to Heat & Fire: As per IS 13779:99
- Electromagnetic Compatibility (EMC): Yes, as per IS 13779:99
- Tamper Detection:
- Immune to stray magnetic fields, abnormal magnetic interference, and DC tampering
- Logs tamper events with date & time stamps
- Disconnects power supply under tamper conditions after a warning
- Communication Protocols: RF 865 – 867 MHz, GPRS 4G (fallback to 2G), Bluetooth, Wi-Fi, RS-485, Optical Port
- Remote Firmware Updates (FOTA): DLMS compliant
- Power Failure Alerts: Sends notifications during power failures
- Self-Diagnostic Feature: Displays all segments on LCD at startup
- Net Metering Support: Yes
- Display Type:Backlit LCD (Green, Pin Type, STN, 120° Viewing Angle)
- Pulse Rate: 1600 imp/kWh
- Memory Retention:EEPROM, more than 20 years
- Measuring Elements: Shunt in Phase, CT in Neutral
- Startup Time:Fully functional within 5 seconds of power application
- Withstand Voltage:
- Impulse Voltage: 8kV, 100E impedancee
- AC Withstand Voltage: 4kV (Body to Terminals)
- Insulation Resistance:
- Frame to Current/Voltage Circuits: > >5MΩ
- Between Circuits: > >50MΩ
- Sealing: Polycarbonate seals with serial number & logo
- Fire Retardant Material:
- Meter Body: PC (Polycarbonate), 2mm Thickness
- Terminal Block: Integral part of the base body
- Terminal Screws: M6, Nickel Plated Brass
- Ultrasonic Welding for Base & Cover: Glued & Locked
- Optical Port:Additional RS232 (D9) Connector for termination in the meter box
- Disconnector Switch:
- Make: HONGFA/KG/EVE
- Two single-pole relays (90A) used in Phase & Neutral Circuit
- Tamper Counters: Yes
- Type Test Certified:IS 16444 Certified
- Power Supply Backup:Super Cap, then Battery
The Mediant Three-Phase Smart Meter is a highly advanced metering solution designed to optimize energy efficiency, ensure accurate billing, and enhance security. Its real-time tracking, remote communication, and tamper-proof features make it a key component for smart grids, industrial applications, and AMI-based energy management systems.
Brief Description of PCP Three-Phase Smart Meter
The PCP Three-Phase Smart Meter is a high-precision energy metering device designed for accurate monitoring, real-time data collection, and secure energy management. It is a 3-phase, 4-wire, direct-reading meter that ensures reliable performance with Class 1 accuracy as per IS 13779/IS 16444 standards. Equipped with tamper detection, net metering capabilities, and multiple communication protocols (RF, GPRS 4G, Bluetooth, Wi-Fi, RS-485, Optical Port), this smart meter is ideal for industrial, commercial, and smart grid applications.With its remote firmware update (FOTA) capabilities, advanced security features, and energy efficiency, the PCP Three-Phase Smart Meter enhances power distribution management while minimizing energy losses. It supports real-time monitoring, automated billing, and seamless integration with Advanced Metering Infrastructure (AMI), making it a smart solution for modern energy systems.
Specifications of PCP Three-Phase Smart Meter
- Type: 3 Phase, 4 Wire, Whole Current Meter, Direct Reading Type
- Accuracy Class: Class 1 as per IS 13779/IS 16444
- Current Range: Ib 5A, Imax 100A
- Operating Voltage:240V (+20%, -40%)
- Operating Frequency:50Hz ± 5%
- Power Consumption:
- Voltage Circuit: 7W (under communication), 5W, 15VA
- Current Circuit: 4VA
- Short Time Overcurrent: 50 Imax for half cycle
- Power Factor Range: Zero Lag to Unity
- Degree of Protection: IP51 as per IS 12063
- Resistance to Heat & Fire: As per IS 13779:99
- Electromagnetic Compatibility (EMC): Yes, as per IS 13779:99
- Tamper Detection:
- Immune to stray magnetic fields, abnormal magnetic interference, and DC tampering
- Logs tamper events with date & time stamps
- Disconnects power supply under tamper conditions after a warning
- Communication Protocols: RF 865 – 867 MHz, GPRS 4G (fallback to 2G), Bluetooth, Wi-Fi, RS-485, Optical Port
- Remote Firmware Updates (FOTA): DLMS compliant
- Power Failure Alerts: Sends notifications during power failures
- Self-Diagnostic Feature: Displays all segments on LCD at startup
- Net Metering Support: Yes
- Display Type:Backlit LCD (Green, Pin Type, STN, 120° Viewing Angle)
- Pulse Rate: 1600 imp/kWh
- Memory Retention:EEPROM, more than 20 years
- Measuring Elements: Shunt in Phase, CT in Neutral
- Startup Time:Fully functional within 5 seconds of power application
- Withstand Voltage:
- Impulse Voltage: 8kV, 100E impedancee
- AC Withstand Voltage: 4kV (Body to Terminals)
- Insulation Resistance:
- Frame to Current/Voltage Circuits: > >5MΩ
- Between Circuits: > >50MΩ
- Sealing: Polycarbonate seals with serial number & logo
- Fire Retardant Material:
- Meter Body: PC (Polycarbonate), 2mm Thickness
- Terminal Block: Integral part of the base body
- Terminal Screws: M6, Nickel Plated Brass
- Ultrasonic Welding for Base & Cover: Glued & Locked
- Optical Port:Additional RS232 (D9) Connector for termination in the meter box
- Disconnector Switch:
- Make: HONGFA/KG/EVE
- Two single-pole relays (90A) used in Phase & Neutral Circuit
- Tamper Counters: Yes
- Type Test Certified:IS 16444 Certified
- Power Supply Backup:Super Cap, then Battery
The Mediant Three-Phase Smart Meter is a highly advanced metering solution designed to optimize energy efficiency, ensure accurate billing, and enhance security. Its real-time tracking, remote communication, and tamper-proof features make it a key component for smart grids, industrial applications, and AMI-based energy management systems.
More Products
Neque porro quisquam est, qui dolorem ipsum quia dolor sit amet, consectetur,
adipisci velit, sed quia non numquam.
Smart Meters
A smart energy meter is an electronic device designed to provide precise measurements of electricity consumption for homes, businesses, or any electrical device. It offers highly accurate data on energy usage, significantly reducing the likelihood of errors in traditional billing systems
Energy Management Software
Mediant Energy's energy management software allows real-time monitoring and control of your energy usage. It optimizes power consumption, enhancing efficiency and reducing electricity costs. The software integrates seamlessly with solar and battery storage systems.
- Energy Meter Headend System
- Energy Meter Data Management System
- Energy Management Mobile Applications
- Microgrid Integrated Management System
- Distributed Energy Resources Grid Management System
- Solar Installation Management Application
Have Questions? Call Us +91 - 8800599854
Got a question or need support? Our team is just a call away. Reach out now—we're here to assist you with anything you need.
Our Certifications & Compliance
Ensuring compliance and trust with industry-standard certifications for safety, accuracy, and reliability.
